Fluke 568 Ex Intrinsically Safe Infrared Thermometer F568 Ex

Name: Fluke 568 Ex Intrinsically Safe Infrared Thermometer F568 Ex
Brand: WUHU WANYI INDUSTRY CO.,LTD
SKU: Fluke 568 Ex Intrinsically Safe Infrared Thermometer F568 Ex
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Fluke

Certification: CCCI

Model Number: Fluke 568 Ex Intrinsically Safe Infrared Thermometer F568 Ex

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Carton

Delivery Time: 7-10days

Payment Terms: Western Union, T/T

Supply Ability: 10-100

Get Best Price

Product Details

Product Description

Highlight:

Fluke 568 Ex Intrinsically Safe Infrared Thermometer F568 Ex

Specifications: Fluke 568 Ex Intrinsically Safe Infrared Thermometer

Specifications
Infrared temperature range	-40°C to 800°C (-40°F to 1472°F)
Infrared accuracy	< 0°C (32°F): ±(1.0°C (±2.0°F) + 0.1°/1°C or°F); > 0°C (32°F): ±1% or ±1.0°C (±2.0°F), whichever is greater
Display resolution	0.1°C / 0.1°F
Infrared spectral response	8 µm to 14 µm
Infrared response time	< 500 ms
Thermocouple type-k input temperature range	-270°C to 1372°C (-454°F to 2501°F)
Thermocouple type-k input accuracy	< -40°C: ±(1°C + 0.2°/1°C) ≥ -40°C: ±1% or 1°C, whichever is greater < -40°F: ±(2°F + 0.2°/1°F) ≥ -40°F: ±1% or 2°F, whichever is greater
D:S (distance to measurement spot size)	50:1
Laser sighting	Single-point laser
Minimum spot size	19 mm (0.75 in)
Emissivity adjustment	By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01
Data storage	99 points
Hi/Low alarms	Audible and two-color visual
Min/Max/Avg/Dif	Yes
Display	Dot matrix with function menus
Backlight	Two levels, normal and extra bright for darker environments
Trigger lock	Yes
Switchable celsius and fahrenheit	Yes
Power	2 AAA/LR03 type-approved batteries (For a list of type-approved batteries, refer to Product Safety Instructions.)
Battery life	4 hours with laser and backlight on; 100 hours with laser and backlight off, at 100% duty cycle
Operating temperature	0°C to 50°C (32°F to 122°F)
Storage temperature	-20°C to 60°C (-40°F to 140°F)
Bead thermocouple type-k range	-40°C to 260°C (-40°F to 500°F)
Bead thermocouple type-k accuracy	±1.1°C (2.0°F) from 0°C to 260°C (32 °F to 500°F), typically within 1.1°C (2.0°F) from -40°C to 0°C (-40°F to 32°F)
