2468A - Pitot/Static Primary Standard F2468A F7750i FRPM4-AD

Name: 2468A - Pitot/Static Primary Standard F2468A F7750i FRPM4-AD
Brand: WUHU WANYI INDUSTRY CO.,LTD
SKU: 2468A - Pitot/Static Primary Standard F2468A F7750i FRPM4-AD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Fluke

Certification: CCCI

Model Number: 2468A - Pitot/Static Primary Standard F2468A F7750i FRPM4-AD

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Carton

Delivery Time: 15-20days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 1000pcs

Get Best Price

Product Details

Product Description

Highlight:

2468A - Pitot/Static Primary Standard F2468A F7750i FRPM4-AD

Specifications: 2468A - Pitot/Static Primary Standard

Pressure Range
Autofloat Mode Standard Piston/Cylinder	Altitude: -2000 to 65,000 feet Airspeed: 175 to 1000 knots Pressure: 1.4 to 103 inHg (47 to 3500 mbar), gauge or absolute
Optional Piston/Cylinder	Pressure: 7.5 to 400 inHg (255 mbar to 13.5 bar), gauge or absolute
Manual Mode	Standard Piston/Cylinder Altitude: -2000 to 95,000 feet Airspeed: 100 to 1000 knots Pressure: 0.4 to 103 inHg (13.5 to 3500 mbar), gauge or absolute
Optional Piston/Cylinder	Pressure: 3.4 to 400 inHg (115 mbar to 13.5 bar), gauge or absolute
Accuracy	Altitude Accuracy Airspeed Accuracy 0 ft 0.5 ft 100 kts 0.003 kts 30,000 ft 1.0 ft 500 kts 0.003 kts 60,000 ft 3.8 ft 1000 kts 0.006 kts

Piston/Cylinders: Standard
Nominal Area	0.52 in2 (3.4 cm2)
Pressure Range	0.4 to 103 inHg (13.5 to 3500 mbar), gauge or absolute
Pressure Accuracy	0.0010% RDG or 0.00003 inHg (0.001 mbar) (whichever is greater)
Pressure Stability	3 ppm per year
Materials	Piston is 440C stainless steel, cylinder is cemented tungsten carbide
Thermal Coefficient	1.5E-05/°C

Piston/Cylinder: Optional
Nominal area	0.13 in2 (0.84 cm2)
Pressure range	3.4 to 400 inHg (115 mbar to 13.5 bar), gauge or absolute
Pressure Accuracy	0.0026% RDG or 0.0008 inHg (0.028 mbar) (whichever is greater)
Pressure Stability	3 ppm per year
Materials	Piston and cylinder are cemented tungsten carbide
Thermal coefficient	9.1E-06/°C

Mass Set
Total mass	26.4 lbs (12 kg)
Maximum Platter Mass	2.2 lbs (1 kg) Includes trim mass set (1 mg to 20g) and storage case

General
Electrical Power	115/230 VAC, 50/60 Hz, 15 W
Temperature	Operating temperature 15°C to 28°C Storage temperature -20°C to 70°C
Humidity	Operating humidity 20 to 75% relative humidity, Noncondensing Storage humidity 0 to 90% relative humidity, Noncondensing
Pressure Medium	High purity nitrogen or dry, clean air with less than 0.5 ppm hydrocarbon and less than 5 ppm H2O content, dew point less than or equal to -50°C, and less than 50 micron particulate size. Although lower quality gas can be used, the frequency of piston/cylinder cleaning will be increased.

Autofloat System
Positive shut-off controller	Automatically generates pressure and maintains piston float position at desired pressure.
Float Position	Inductive sensor Float position resolution: 0.001 in or 0.001 cm Sink rate resolution: 0.001 inch/minute or 0.001 cm/minute
Piston Temperature	Four-wire 100W PRT Accuracy: ±0.1°C per year Resolution: 0.01°C
Air Density	Sensor types Temperature: thin film platinum 1000W RTD Humidity: capacitive IC humidity sensor Barometric pressure: piezoresistive, monolithic silicon pressure transducer Accuracy Temperature: ±2°C Humidity: ±15% Pressure: ±5 mmHg
Vacuum Reference	Thermopile sensor Accuracy: 10% of reading or 10 mTorr (whichever is greater) Resolution: 1 mTorr
Barometric Reference Sensor	Accuracy: better than ±0.0008 inHg Resolution: 0.0003 in.Hg

Computer Interface
Requirements	Pentium level processor, RS-232C interface, monitor, mouse or other pointing device, keyboard; program requires 2 MB available hard disk space; Windows 95 or higher

Manual Control Pack
Manual Control Pack	For users who prefer a manually operated system, the manual control pack can be provided with the Model 2468 instead of the autofloat controller. The manual control pack includes pressure and vacuum inlet valves, precise pressure adjuster for fine pressure control, reference gauge and vent valve.
