PLS 3G Laser Level FPLS 3G

Name: PLS 3G Laser Level FPLS 3G
Brand: WUHU WANYI INDUSTRY CO.,LTD
SKU: PLS 3G Laser Level FPLS 3G
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Fluke

Certification: CCCI

Model Number: PLS 3G Laser Level FPLS 3G

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Carton

Delivery Time: 15-20days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 1000pcs

Get Best Price

Product Details

Product Description

Highlight:

PLS 3G Laser Level FPLS 3G

Product overview: PLS 3G Laser Level

The new PLS 3G green laser levels offer the durability and precision you expect from PLS, a Fluke Company. Our new laser level platform offers a pendulum lock platform for safe transport and tilt mode functionality. The fast settling, self-leveling pendulum gives you accurate point and reference lines almost instantly.

This professional self-leveling three-point red and green laser level allows for fast, accurate layout of reference points and is excellent for steel stud framing, HVAC installation, electrical and residential construction
The PLS 3G green beam laser is up to three times brighter than the PLS 3R red beam, making it ideal for projects over longer distances or with lower lighting.

Specifications: PLS 3G Laser Level

PLS 3G
Battery	3 x AA Alkaline IEC LR6
Battery Life, Continuous Use	Red	≥ 30 hours
Battery Life, Continuous Use	Green	≥ 16 hours
Point Laser Direction	90° up, down, forward
Working Range	≤ 30 m (100 ft.)
Accuracy	≤ 3 mm @ 10 m (≤ 1/8 in at 30 ft.)
Laser Leveling	System	Automatic, Pendulum
Laser Leveling	Range	4 °
Point Laser Diameter	≤ 4 mm at 5 m
Temperature	Operating	-10 °C to 50 °C (14 °F to 122 °F)
	Storage	15 cm x 9 cm x 3 cm (6 in x 3.6 in x 1.3 in)
	With Batteries	-18 °C to 50 °C (-0.4 °F to 122 °F)
	Without Batteries	-20 °C to 70 °C (-13 °F to 158 °F)
Relative Humidity	0 % to 90 % (0 °C to 35 °C)
	0 % to 75 % (35 °C to 40 °C)
	0 % to 45 % (40 °C to 50 °C)
Size (H x W X L)	116 mm x 64 mm x 104 mm (4.6 in x 2.5 in x 4.1 in)
Weight	~0.6 kg (1.3 lb.)
Safety	IEC 61010-1: Pollution Degree 2
Laser	IEC 60825-1:2014 Class 2
Light Source	Semiconductor laser diode
Max Output Power	< 1 mW
Wavelength	Red	635 nm ± 5 nm
Wavelength	Green	525 nm ± 5 nm

Kit includes floor stand and L-bracket for fast, easy overhang and centerline measurements.
