PLS 3x360G Three-plane Laser Level FPLS 3X360G

Name: PLS 3x360G Three-plane Laser Level FPLS 3X360G
Brand: WUHU WANYI INDUSTRY CO.,LTD
SKU: PLS 3x360G Three-plane Laser Level FPLS 3X360G
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Fluke

Certification: CCCI

Model Number: PLS 3x360G Three-plane Laser Level FPLS 3X360G

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Carton

Delivery Time: 15-20days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 1000pcs

Get Best Price

Product Details

Product Description

Highlight:

PLS 3x360G Three-plane Laser Level FPLS 3X360G

Product overview: PLS 3x360G Three-plane Laser Level

Lighten your toolbelt with the 3×360 green laser level. This versatile combination laser level features best-in-class accuracy as well as a rechargeable battery pack with charging adapter and a pendulum lock for added protection during transportation.

First PLS laser with 3-beam laser technology integrated to automatic pendulum
Use the superior-range detector with the 3x360G for your challenging work environments
Includes rechargeable Li-ion battery pack, power supply, magnetic L-bracket, green reflective target, canvas pouch and blow mold case

Specifications: PLS 3x360G Three-plane Laser Level

Laser Levels	PLS 3x360G
Battery	Lithium-Ion, 3.6V, 5200 mh (RBP5)
Battery Life, Continuous Use	3 beams: ≥ 5 hours; 1 beam: ≤ 17 hours
Line Fan Angle
Horizontal	360°
Vertical	360°
Side Vertical	360°
Working Range
Without Line Detector	35 m (115 ft.)
With Line Detector	65 m (210 ft.)
Laser Leveling
System	Automatic, Pendulum
Range	Self-leveling: ≤ 4°; Out of self-levelling: > 6°
Temperature
Operating	-10 °C to 50 °C (14 °F to 122 °F)
Storage
With Batteries	-18 °C to 50 °C (-0.4 °F to 122 °F)
Without Batteries	-20 °C to 70 °C (-13 °F to 158 °F)
Relative Humidity	0 % to 90 % (0 °C to 35 °C)
	0 % to 75 % (35 °C to 40 °C)
	0 % to 45 % (40 °C to 50 °C)
IP Rating	IP 54
Drop Test	(1 M) 3.28 ft
Size (H x W x L) with Battery	5.12 in x 3.58 in x 5.25 in (13 cm x 9.09 cm x 13.33 cm)
Weight with Battery	1.76 lbs (0.8 kg)
Safety	IEC 61010-1: Pollution Degree 2
Laser	IEC 60825-1:2014 Class 2
Light Source	Semiconductor laser diode
Max Output Power	< 1 mW
Wavelength
Green	520 nm ± 10 nm
Electromagnetic compatibility (EMC)
International	IEC 61326-1: Basic Electromagnetic Environment CISPR 11: Group 1, Class B
