SICK Gas Analyzers SMC9021 A continuous emission monitoring system

Name: SICK Gas Analyzers SMC9021 A continuous emission monitoring system
Brand: WUHU WANYI INDUSTRY CO.,LTD
SKU: Gas Analyzers SMC9021 A continuous emission monitoring system
Availability: InStock

Product Details

Place of Origin: China

Brand Name: SICK

Certification: CCCI

Model Number: Gas Analyzers SMC9021 A continuous emission monitoring system

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Carton

Delivery Time: 10-15days

Payment Terms: T/T

Supply Ability: 100

Get Best Price

Product Details

Product Description

Highlight:

SICK Gas Analyzers SMC9021 A continuous emission monitoring system

Measured values

CO, CO₂, NO_x, O₂, SO₂

Performance-tested measurands

CO, CO₂, NO_x, O₂, SO₂

Measurement principles

NDIR spectroscopy, electrochemical cell

Gas flow rate
	10 l/min ... 60 l/min

Measuring ranges
CO	0 ... 500 mg/m³ / 0 ... 2,500 mg/m³
NO	0 ... 500 mg/m³ / 0 ... 2,500 mg/m³
O₂	0 ... 21 Vol.-%
SO₂	0 ... 500 mg/m³ / 0 ... 2,500 mg/m³

Certified measuring ranges
CO	0 ... 2,500 mg/m³
NO	0 ... 2,500 mg/m³
SO₂	0 ... 2,500 mg/m³

Response time (t₉₀)

≤ 15 s

Accuracy
	≤ ± 1 % Of measuring range full scale

Sensitivity drift
	≤ ± 1 %: of measuring range full scale per week

Zero point drift
	≤ ± 1 %: of measuring range full scale per week

Reference point drift
	≤ ± 1 %: of measuring range full scale per week

Detection limit
	≤ 1 %

Resolution
	≤ 1 %

Process temperature
	≤ +300 °C

Process pressure
	–100 hPa ... 100 hPa Relative

Ambient temperature
	+5 °C ... +35 °C

Storage temperature
	–20 °C ... +70 °C

Ambient pressure
	900 hPa ... 1,100 hPa

Enclosure rating
	IP40

Analog outputs

4 outputs:
4 ... 20 mA

Analog inputs

Optional 2 inputs possible

Digital outputs

Optional 4 outputs possible

Digital inputs

Optional 4 inputs possible

Dimensions (W x H x D)
	800 mm x 2,100 mm x 800 mm

Weight
	≤ 300 kg

Energy supply
Voltage	220 V AC
Frequency	50 Hz
Power consumption	≤ 2,000 VA

Auxiliaries
Instrument air: ≥ 4 bar	≤ 100 l/min During backflushing

Sample gas connections
Sample gas inlet	8 mm diameter
Exhaust gas outlet	14 mm diameter

Auxiliary gas connections
Instrument air	DN 6/8

Corrective functions

Manual or automated adjustment with test gases

System components

Gas sampling unit

Sample gas line

Analyzer cabinet

Connection unit

Integrated components

Temperature sensor

Pressure sensor

Humidity sensor

Flow sensor

SMC900
